. :: 500 Meter Capacity Drilling Machines ::.

Deck Engine: 280 HP Diesel Engine, Transmission 90’s Fuller

Tower: The tower top is 14 meters long from 3.5 “pipe and works with 9 roller pulleys.

Chain Box: (Middle Transmitter) 1 input, 7 outputs, 1 “4 rows of double chain, double transmission unit, Rotary gearbox. ZF90, winch gearbox ZF65

Rope Winder: It has 5 + 5, 10 lining system. Ropes are 18 mm thick steel core rope.

Rotary : 230 mm 3/1 rotation speed.

Water Head: Bearing inner diameter 130 mm, outer diameter 250 mm shaft thickness 150 mm, length 600 mm, water head outer diameter 320 mm, water nozzle wedge diameter 130 mm, inner diameter 90 mm

Centrifuge: Large type outlet, 4 ”

Welding Machine: 400 Amps

Machine Balance: Balance is provided with 4 hydraulic legs.

Kelly: It is 120 mm x 120 mm four corners, 16 mm in thickness, 11 meters in length and can be changed on request.

Water Hoses: 3 “(R2). Absorbent hoses are in a 4-clapper system.

Pulleys: 4 treble for Kelly are 2 to hang. 4 + 2

Hydraulic Pump: 9 pistons, maximum pressure 180 bar.

Machine Equipment: Slip, maneuver head, vise, 8.5 – 12.5 – 17.5 drill shank

750

. :: 750 Meter Capacity Drilling Machines ::.

Deck Engine: 270 HP Diesel Engine, Transmission 90’s Fuller

Tower: The tower top is 14 meters long from 3.5 “pipe and works with 9 roller pulleys.

Chain Box: (Middle Transmitter) 1 input, 7 outputs, 1 “4 rows of double chain, double transmission unit, Rotary gearbox. ZF90, winch gearbox ZF65

Rope Winder: It has 5 + 5, 10 lining system. Ropes are 18 mm thick steel core rope.

Rotary : 230 mm 3/1 rotation speed.

Mud Pump: All steel cast 5×6 750 meters capacity pump can be changed upon request.

Water Head: Bearing inner diameter 130 mm, outer diameter 250 mm shaft thickness 150 mm, length 600 mm, water head outer diameter 320 mm, water nozzle wedge diameter 130 mm, inner diameter 90 mm

Centrifuge: Large type outlet, 4 ”

Welding Machine: 400 Amps

Machine Balance: Balance is provided with 4 hydraulic legs.

Kelly: It is 120 mm x 120 mm four corners, 16 mm in thickness, 11 meters in length and can be changed on request.

Water Hoses: 3 “(R2). Absorbent hoses are in a 4-clapper system.

Pulleys: 4 treble for Kelly is 2 to hang. 4 + 2

Hydraulic Pump: 9 pistons, maximum pressure 180 bar.

Machine Equipment: Slip, maneuver head, vise, 8.5 – 12.5 – 17.5 drill shank

1000

1000

.:: 1000 Metre Kapasiteli Sondaj Makinaları ::.

Güverte Motoru : 422 HP Dizel Motor, 2 ADET

Kule : Kule 100*100*6 mm profilden, 14,5 metre boyunda, kule tepesi 12 adet rulmanlı kasnak ile çalışmaktadır.

Zincir Kutusu : (Orta Aktarıcı) 2 giriş, 7 çıkış, 1″ ¼ 4 sıra çift zincir, çift şanzuman ünitelidir.

Halat Sarıcı : 4+4=8 balatalı büyük tip sistemindedir. Halatlar 20 mm kalınlığında, çelik özlü halattır.

Rotary : 230 mm 3/1 rotation speed.

Su Başlığı : Rulman iç çapı 140 mm, dış çapı 250 mm mil kalınlığı150 mm, boy 600 mm, su başlığı dış çapı 320 mm, su başlığı takozu çapı 120 mm, iç çap 80 mm

Santrifüj : Büyük tip çıkış, 5″

Altarnatör : 35 KW

Makina Dengesi : 4 adet hidrolik ayaklarla, denge sağlanır.

Kelly : 140 mm x 130 mm dört köşe, orjinal USA 11,5 metre uzunluğundadır.

Su Hortumları : 3″ (R2) dir. Emici hortumlar 4’lük klepeli sistemindedir.

Palangalar : Kelly için 4 , tij asılmak için 3’lidir. 4+2

Hidrolik Pompa : 9 piston, maksimum basınç 180 bar.

Makina Ekipmanları : Slip, manevra başlığı, mengene, 8,5 – 12,5 – 17,5 matkap sapları

Çamur pompası( DONKY): 7,5 X 10
